The FAFNIR 200DD is a compact single-row deep groove ball bearing designed primarily for radial loading while also supporting moderate axial load in both directions.

Its dimensional envelope is:

10 × 30 × 9 mm

which corresponds to the modern standard:

6200

The DD suffix is particularly important. In historical FAFNIR nomenclature:

D = Single Shield
DD = Double Shield

Therefore, the closest modern starting point for cross-reference is normally the:

6200-2Z / 6200ZZ

double-metal-shielded family rather than a rubber-sealed 6200-2RS. BDS Bearing

⚙️ Applications

• Small electric motors
• Pumps
• Fans and blowers
• Gearboxes
• Power tools
• Light conveyor systems
• Industrial instruments
• Small rollers
• Agricultural equipment
• General rotating machinery

🎯 Benefits

✔ Standard 10 × 30 × 9 mm dimensions

✔ Single-row deep groove construction

✔ Double metal shields

✔ Good grease retention

✔ Lower running friction than typical contact rubber seals

✔ Good radial-load capability

✔ Supports moderate axial load in both directions

✔ Suitable for relatively high-speed applications when operating conditions permit

✔ Modern 6200-2Z / 6200ZZ replacements widely available

🧠 Technical Insight

• FAFNIR 200DD
• FAFNIR Light 200 Series
• Deep Groove Ball Bearing
• Bore 10 mm
• OD 30 mm
• Width 9 mm
• Double Shielded
• DD = Double Shield
• Modern Dimensional Reference: 6200

✅ Key Features

• FAFNIR Bearing
• Model 200DD
• Light 200 Series
• Single-Row Deep Groove Ball Bearing
• 10 mm Bore
• 30 mm OD
• 9 mm Width
• Double Metal Shield Configuration

📊 Specifications

Brand: FAFNIR

Model / Bearing Number: 200DD

Series: FAFNIR Light 200 Series

Modern Dimensional Reference: 6200

Product Type: Deep Groove Ball Bearing

Bearing Type: Single-Row Radial Ball Bearing

Construction: Standard Deep Groove / Non-Filling-Slot Type

Bore Diameter (d): 10.00 mm

Outside Diameter (D): 30.00 mm

Width (B): 9.00 mm

Rolling Elements: Ball

Number of Rows: 1

Closure: Double Shielded

FAFNIR Suffix DD: Double Shield

Shield Type: Metal shields

Primary Load: Radial

Axial Load Capability: Moderate axial load in both directions depending on operating conditions

Lubrication: Normally grease-retaining shielded-bearing configuration

Internal Clearance: Not defined by the basic 200DD designation; verify if Normal, C3, or another clearance is required

Cage: Verify original FAFNIR production specification

Dynamic Load Rating: Verify original FAFNIR data or exact modern replacement specification

Static Load Rating: Verify original FAFNIR data or exact modern replacement specification

Speed Rating: Depends on grease, clearance, fit, temperature, load, and replacement manufacturer

Shaft Fit: Nominal 10 mm shaft

Housing Fit: Nominal 30 mm bearing seat

The original FAFNIR catalog confirms that the shielded bearing retains the dimensions and load-rating basis of its corresponding basic bearing. BDS Bearing

🔁 Equivalent

Suitable replacement or cross-reference candidates include:

• FAFNIR 200DD
• SKF 6200-2Z
• FAG 6200-2Z
• NSK 6200ZZ
• NTN 6200ZZ
• KOYO 6200ZZ
• NACHI 6200ZZ
• MRC 200SZZ
• 10x30x9 Double-Shielded Deep Groove Ball Bearing

FAFNIR 200DD → Modern 6200 Family

The dimensional relationship is:

FAFNIR 200DD = 10 × 30 × 9 mm

which matches:

6200

Because the FAFNIR DD suffix specifically means Double Shield, the most technically appropriate modern family to investigate first is:

6200-2Z / 6200ZZ BDS Bearing

Important: DD vs PP

Historical FAFNIR nomenclature should not be mixed indiscriminately.

For FAFNIR:

DD → Double Shield

Other FAFNIR designations, such as PP, are used for different closure constructions in some product families.

Therefore:

FAFNIR 200DD ≠ automatically FAFNIR 200PP

even though both may use the same basic 10 × 30 × 9 mm envelope.

6200-2Z vs 6200-2RS

Both commonly use:

10 × 30 × 9 mm

but closure design differs.

6200-2Z / ZZ

• Metal shields on both sides
• Lower friction
• Good grease retention
• Generally better suited to higher speed
• Helps exclude larger dust and debris

6200-2RS / 2RSH

• Rubber seals
• Better exclusion of fine dust and moisture
• Higher friction
• Usually lower allowable speed than comparable shielded versions

For the original FAFNIR 200DD, the 6200-2Z / ZZ family is therefore normally a closer constructional cross-reference than 6200-2RS.

Important Cross-Reference Consideration

Before replacing FAFNIR 200DD, verify:

• Bore = 10 mm
• OD = 30 mm
• Width = 9 mm
• Double metal shields
• Internal clearance
• Cage
• Lubricant
• Precision class
• Operating speed
• Load requirement
• Shaft fit
• Housing fit

(Always verify the original bearing marking and machine requirements before selecting SKF 6200-2Z, FAG 6200-2Z, NTN 6200ZZ, NSK 6200ZZ, MRC 200SZZ, or another replacement.)
