The MRC 122KS is a large extra-light-series deep groove ball bearing designed primarily for radial loading, while also supporting moderate axial loads in both directions.

Its dimensional envelope is:

110 × 170 × 28 mm

which corresponds to the modern standardized:

6022

The bearing uses a conventional single-row, non-filling-slot / Conrad-type deep groove construction, providing low friction and good high-speed capability relative to heavier bearing series of similar bore size.

⚙️ Applications

• Large electric motors
• Industrial pumps
• Fans and blowers
• Gearboxes
• Conveyor systems
• Processing machinery
• Industrial rollers
• Agricultural machinery
• Power-transmission equipment
• General rotating machinery

🎯 Benefits

✔ Standard 110 × 170 × 28 mm dimensions

✔ Extra-light-series construction

✔ Single-row deep groove design

✔ Good radial-load capability

✔ Moderate axial-load capability in both directions

✔ Open construction allows flexible lubrication arrangements

✔ Low-friction operation

✔ Modern 6022 replacements are widely available

🧠 Technical Insight

• MRC 122KS
• MRC 100-KS Extra Light Series
• Deep Groove Ball Bearing
• 110 mm Bore
• 170 mm Outside Diameter
• 28 mm Width
• Single-Row Radial Bearing
• Non-Filling-Slot / Conrad Type
• Modern Dimensional Reference: 6022

✅ Key Features

• MRC (SKF) Bearing
• Model 122KS
• 100-KS Extra Light Series
• Single-Row Deep Groove Ball Bearing
• 110 mm Bore
• 170 mm OD
• 28 mm Width
• Open-Type Configuration

📊 Specifications

Brand: MRC (SKF)

Model / Bearing Number: 122KS

Series: MRC 100-KS Extra Light Series

Modern Dimensional Reference: 6022

Product Type: Deep Groove Ball Bearing

Bearing Type: Single-Row Radial Ball Bearing

Construction: Non-Filling-Slot / Conrad-Type

Bore Diameter (d): 110.00 mm

Outside Diameter (D): 170.00 mm

Width (B): 28.00 mm

Rolling Elements: Ball

Number of Rows: 1

Closure: Open, subject to verification of the actual bearing marking

Seal / Shield: None indicated by the supplied designation

Primary Load: Radial

Axial Load Capability: Moderate axial load in both directions depending on operating conditions

Lubrication: Requires appropriate grease or oil lubrication from the machine / bearing arrangement

Internal Clearance: Not specified by the basic 122KS designation; verify Normal, C3, or other clearance if critical

Cage: Verify original MRC production specification

Dynamic Load Rating: Verify original MRC or modern manufacturer specification

Static Load Rating: Verify original MRC or modern manufacturer specification

Speed Rating: Depends on lubricant, internal clearance, shaft/housing fit, temperature, and load

Shaft Fit: Nominal 110 mm shaft

Housing Fit: Nominal 170 mm bearing seat

🔁 Equivalent

Suitable dimensional replacement or cross-reference candidates include:

• MRC 122KS
• SKF 6022
• FAG 6022
• NSK 6022
• NTN 6022
• KOYO 6022
• NACHI 6022
• TIMKEN 6022
• 110x170x28 Open Deep Groove Ball Bearing

MRC 122KS → Modern 6022 Family

The dimensional relationship is:

MRC 122KS = 110 × 170 × 28 mm

which corresponds to:

6022

For an original open bearing, the closest modern starting point is:

6022 Open

If the operating environment requires a different closure, shielded or sealed 6022 variants may exist depending on manufacturer, but they should not automatically replace the open 122KS without checking speed, lubrication, and temperature requirements.

Important: 122KS vs 122KSFF

The suffix is important.

122KS
→ Base 100-KS-series bearing, typically open execution

122KSFF
→ Protected on both sides / typically double-shielded MRC execution

Therefore, 122KS and 122KSFF should not automatically be treated as identical, even though their basic dimensions may match.

Important Cross-Reference Consideration

Before replacing MRC 122KS with a modern 6022, verify:

• Bore = 110 mm
• OD = 170 mm
• Width = 28 mm
• Open construction
• Internal clearance
• Cage construction
• Lubrication method
• Precision class
• Operating speed
• Load requirements
• Shaft fit
• Housing fit

(Always verify the complete marking on the original MRC 122KS before selecting SKF 6022, FAG 6022, NTN 6022, NSK 6022, or another replacement.)
